MC4 Connector With DC Fuse 1000V

Features:

• 1000V DC MC4 inline PV fuse
• IP67, UV‑resistant PPO housing
• 10A/15A/20A/30A ratings (variant)
• Fits 2.5–6 mm² PV cable, low resistance
• Secure MC4 lock with anti‑release tabs

Specifications:

• Type: MC4 inline fuse connector (DC)
• Voltage: up to 1000V DC (model dependent)
• Current: 10–30A fuse link (select rating)
• Cable range: 2.5–6 mm² (14–10 AWG)
• Materials/Protection: PPO housing, tinned Cu contacts, IP67, −40 to +90°C

Uses:

• PV string over‑current protection
• Panel branch protection in arrays
• Off‑grid and hybrid inverter inputs
• Rooftop and ground‑mount arrays
• Quick repair/retrofit of DC lines

Package Includes:

1 x Fuse Type MC4 1000V DC
